Meter Specifications
|
Feature |
Specifications |
|
Methodology |
Reflectance Photometer |
|
Test Time |
<15 seconds |
|
Measurement Range |
4.5-25.6 g/dL, 45-256 g/L, 2.8-15.9 mmol/L |
|
Specimen |
Whole blood |
|
Specimen Volume |
10 ¦ÌL |
|
Power Source |
3 AAA batteries (1.5V) |
|
AC Adapter (Mini USB, 5V dc, 50 mA) |
|
|
Battery Life |
360 hours or 2,700 tests |
|
Units of Measure |
g/dL, g/L, mmol/L |
|
Memory |
1,000 records |
|
Automatic Shut Off |
8 minutes after last use |
|
Meter Size |
127 mm ¡Á 58 mm ¡Á 25 mm (5.0¡± ¡Á 2.28¡± ¡Á0.09¡±) |
|
Display Size |
39 mm ¡Á 37 mm (1.54¡± ¡Á1.46¡±) |
|
Weight |
102 g (without batteries) |
|
Meter Storage Conditions |
0 - 50 oC (32 -122 oF); ¡Ü90£¥ RH |
|
Operating Conditions |
10 - 40 oC (50 -104 oF); ¡Ü90£¥ RH |
|
Meter Connectors |
USB cable for Data Transfer or Power (optional) |
